902000S1

Regular price$879.00
/
Shipping calculated at checkout.

Size

The Skylord EXP LED Bars are designed for drivers who want more than just powerful light output. It combines extreme performance with wireless control, simplified installation, and intelligent integration through the SKYN1 EXP system.

The Skylord EXP LED is engineered to impress and delivers both performance and Bluetooth installation. Each model has an E-mode that is E-approved R148/R149 with reference number 20. They offers both white and amber position lights, as well as a newly developed beam pattern for maximum visibility straight ahead and to the sides, near and far from the vehicle. The housing are IP-rated IP69K and cast in one piece, and the Skylord is covered by Strands’ 3-year warranty.

The Skylord EXP is compatible with the Skyn1 EXP wireless system and can only be used with the EXP control (Part No. 907851). The LED bar connects wirelessly and automatically via Bluetooth® wireless technology. All functions, like E-mode, Xperience mode, and position lights, are assigned to a button on the EXP control. This means you can control all functions on all EXP lights with ease with a single control.

The LED bars features a built-in relay and includes a 2.5-meter cable. Installation accessories are included.

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Strands Lighting Division is under license. Other trademarks and trade names are those of their respective owners.

These lights are sold individually

Size: 10" Size: 20" Size: 30" Size: 40"
Unit: PCS Unit: PCS Unit: PCS Unit: PCS
Voltage (DC): 10–32V DC Voltage (DC): 10–32V DC Voltage (DC): 10–32V DC Voltage (DC): 10–32V DC
Theoretical effect: 90W Theoretical effect: 190W Theoretical effect: 300W Theoretical effect: 370W
Consumption: 82W Consumption: 180W Consumption: 294W Consumption: 352W
Functions: Amber Pos. / White Pos. / Xperience mode / E-approved mode Functions: Amber Pos. / White Pos. / Xperience mode / E-approved mode Functions: Amber Pos. / White Pos. / Xperience mode / E-approved mode Functions: Amber Pos. / White Pos. / Xperience mode / E-approved mode
Consumption specific function: White Pos. 6W / Amber Pos. 6W / E-mode 37W / X-mode 82W Consumption specific function: E-mode 74W / White Pos. 12W / Amber Pos. 12W / X-mode 180W Consumption specific function: E-mode 84W / White Pos. 12.5W / Amber Pos. 12.5W / X-mode 294W Consumption specific function: Amber Pos. 13W / E-mode 76W / White Pos. 13W / X-mode 352W
Theoretical lumen: 10800lm Theoretical lumen: 23000lm Theoretical lumen: 33000lm Theoretical lumen: 39000lm
Actual lumen: 7800lm Actual lumen: 16600lm Actual lumen: 26000lm Actual lumen: 31500lm
1 lux @: 542m 1 lux @: 754m 1 lux @: 1096m 1 lux @: 1207m
Color temperature: 5700K Color temperature: 5700K Color temperature: 5700K Color temperature: 5700K
Beam pattern: Extended Beam Beam pattern: Long-distance beam Beam pattern: Long-distance beam Beam pattern: Long-distance beam
Beam angle: 13.6° Beam angle: 12.1° Beam angle: 12.1° Beam angle: 13.2°
Connection: Cable Connection: Cable Connection: Cable Connection: Cable
Cable length: 2500mm Cable length: 2500mm Cable length: 2500mm Cable length: 2500mm
Color housing: Black Color housing: Black Color housing: Black Color housing: Black
Color lens: Clear Color lens: Clear Color lens: Clear Color lens: Clear
Color LED's: White / Amber Color LED's: White / Amber Color LED's: White / Amber Color LED's: White / Amber
Material bracket: Aluminium alloy Material bracket: Aluminium alloy Material bracket: Aluminium alloy Material bracket: Aluminium alloy
Material housing/chassi: Aluminium Material housing/chassi: Aluminium Material housing/chassi: Aluminium Material housing/chassi: Aluminium
Material lens: Polycarbonate Material lens: Polycarbonate Material lens: Polycarbonate Material lens: Polycarbonate
Length: 266mm Length: 506mm Length: 746mm Length: 986mm
Depth: 78mm Depth: 78mm Depth: 78mm Depth: 78mm
Height: 67.5mm Height: 67.5mm Height: 67.5mm Height: 67.5mm
Height including bracket: 73.9mm Height including bracket: 73.9mm Height including bracket: 73.9mm Height including bracket: 73.9mm
Weight: 2kg Weight: 3.16kg Weight: 4.5kg Weight: 4.92kg
IP-class: IP68/69K IP-class: IP68/69K IP-class: IP68/69K IP-class: IP68/69K
Operating temperature: -35° – +60°C Operating temperature: -35° – +60°C Operating temperature: -35° – +60°C Operating temperature: -35° – +60°C
E-approved: Yes E-approved: Yes E-approved: Yes E-approved: Yes
ECE approval: R10.06 / R148 / R149 / CE-RED ECE approval: R10.06 / R148 / R149 / CE-RED ECE approval: R10.06 / R148 / R149 / CE-RED ECE approval: R10.06 / R148 / R149 / CE-RED
Reference number: 20 Reference number: 20 × 2 Reference number: 20 × 2 Reference number: 20 × 2
Other approval: SIG Bluetooth Other approval: SIG Bluetooth Other approval: SIG Bluetooth Other approval: SIG Bluetooth
Additional information: Works with SKYN1 EXP CONTROLLR 907851S1 Additional information: Works with SKYN1 EXP CONTROLLR 907851S1 Additional information: Works with SKYN1 EXP CONTROLLR 907851S1 Additional information: Works with SKYN1 EXP CONTROLLR 907851S1
