Siberia Single Row (12"-50")

Siberia Single Row (12"-50")

Siberia Single Row (12"-50")

Siberia Single Row (12"-50")

Siberia Single Row (12"-50")

Siberia Single Row (12"-50")

Siberia Single Row (12"-50")

Siberia Single Row (12"-50")

$246.00

Shipping calculated at checkout.

Description
Specifications
Manual

Description

Welcome to the Siberia Series single row LED light bars. These LED bars are truly innovative, combining 2 separate lighting functions with cutting edge design.

The power of the spot beam on the 12" bar gives you an extremely long and concentrated light forward where you need it. The power of the combo beam on the longer bars gives you a perfect balance between length and width. All are E-approved, providing exceptional range, regardless of bar length. The second feature is a dual colour position light, which illuminates with your choice of output – a cool white or rich amber colour. This feature gives you the option of linking to daytime running lights, flashers or other functions and customizes the appearance of your vehicle.

This light is sold individually and does not include a harness (whip included on models with DT connector)

Wiring Harnesses: For 1 Light

Specifications

12 Inch

22 Inch

32 Inch

42 Inch

50 Inch

VOLTAGE

10-40V DC

10-40V DC

10-40V DC

10-40V DC

10-40V DC

CONSUMPTION (w) 12V/24V

32/32

59/59

95/95

130/130

155/155

THEORETICAL LUMEN

4000

8000

12000

16000

19200

ACTUAL LUMEN

2200

4254

5641

7434

8570

1 LUX @ (m)

368

447

444

464

443

IP CLASS

IP67/IP69K

IP67/IP69K

IP67/IP69K

IP67/IP69K

IP67/IP69K

BEAM PATTERN

Spot

Combo

Combo

Combo

Combo

POSITION LIGHT

Yes, amber and white

Yes, amber and white

Yes, amber and white

Yes, amber and white

Yes, amber and white

CONNECTION

DT4

DT4

DT4

Cable

Cable

CABLE LENGTH (mm)

500

500

500mm

2500

2500mm

MATERIAL HOUSING

Aluminium

Aluminium

Aluminium

Aluminium

Aluminium

MATERIAL LENS

Polycarbonate

Polycarbonate

Polycarbonate

Polycarbonate

Polycarbonate

LENGTH (mm)

300,6

555,6

813,6

1065,6

1269,6

DEPTH (mm)

55,5

55,5

55,5

55,5

55,5

HEIGHT (mm)

45

45

45

45

45

HEIGHT INCLUDING BRACKET (mm)

65

65

65

65

65

OPERATING TEMPERATURE

-30°C - +65°C

-30°C - +65°C

-30°C - +65°C

-30°C - +65°C

-30°C - +65°C

E-APPROVED

ECE R112, R7

ECE R112, R7

ECE R112, R7

ECE R112, R7

ECE R112, R7

EMC-CERTIFICATE

ECE R10

ECE R10

ECE R10

ECE R10

ECE R10

Manual

Download 12" Manual

Download 22" Manual

Download 32" Manual

Download 42" Manual

Download 50" Manual
